Activiti 8

<dependency>
   <groupId>org.activiti</groupId>
   <artifactId>activiti-spring-boot-starter</artifactId>
   <version>8.6.0</version>
</dependency>

spring:
  activiti:
    database-schema-update: true # Auto create/update schema
    history-level: full # Lưu full audit (activity, variable, task details)
    async-executor-activate: true # Enable async job execution
    check-process-definitions: false # Không auto-deploy từ classpath

  datasource:
    url: jdbc:postgresql://localhost:5432/bpm_db
    username: ${DB_USERNAME}
    password: ${DB_PASSWORD}
    hikari:
      maximum-pool-size: 30 # Activiti cần nhiều connections cho async jobs

@Configuration
public class ActivitiConfig {

   @Bean
   public SpringProcessEngineConfiguration processEngineConfiguration(
           DataSource dataSource,
           PlatformTransactionManager transactionManager,
           List<JavaDelegate> delegates) {

       SpringProcessEngineConfiguration config = new SpringProcessEngineConfiguration();
       config.setDataSource(dataSource);
       config.setTransactionManager(transactionManager);
       config.setDatabaseSchemaUpdate("true");
       config.setAsyncExecutorActivate(true);
       config.setHistoryLevel(HistoryLevel.FULL);

       // Custom ID generator (UUID thay vì sequential)
       config.setIdGenerator(new StrongUuidGenerator());

       // Async executor tuning
       config.setAsyncExecutorCorePoolSize(5);
       config.setAsyncExecutorMaxPoolSize(20);
       config.setAsyncExecutorDefaultAsyncJobAcquireWaitTime(5000);

       return config;
   }
}

@Service
@RequiredArgsConstructor
@Slf4j
public class ProcessDefinitionService {

   private final RepositoryService repositoryService;

   /**
    * Deploy BPMN XML. Mỗi lần deploy cùng key → version tăng.
    * Instances đang chạy KHÔNG bị ảnh hưởng — giữ version cũ.
    * Instances mới start sẽ dùng version mới nhất.
    */
   public DeploymentResult deploy(String bpmnXml, String processName, String workspaceId) {
       Deployment deployment = repositoryService.createDeployment()
           .name(processName)
           .tenantId(workspaceId)  // Multi-tenant isolation
           .addString(processName + ".bpmn20.xml", bpmnXml)
           .deploy();

       // Lấy definition mới deploy
       ProcessDefinition definition = repositoryService.createProcessDefinitionQuery()
           .deploymentId(deployment.getId())
           .singleResult();

       log.info("Deployed process | name={} | version={} | deploymentId={}",
           definition.getName(), definition.getVersion(), deployment.getId());

       return new DeploymentResult(deployment.getId(), definition.getId(), definition.getVersion());
   }

   /**
    * Lấy tất cả versions của 1 process definition.
    * Hữu ích cho rollback: activate version cũ, suspend version mới.
    */
   public List<ProcessDefinitionDTO> getVersions(String processKey, String workspaceId) {
       return repositoryService.createProcessDefinitionQuery()
           .processDefinitionKey(processKey)
           .processDefinitionTenantId(workspaceId)
           .orderByProcessDefinitionVersion().desc()
           .list()
           .stream()
           .map(this::toDTO)
           .toList();
   }

   /**
    * Suspend definition → không thể start instances mới.
    * Useful khi phát hiện bug trong process, cần "pause" nó.
    */
   public void suspend(String definitionId) {
       repositoryService.suspendProcessDefinitionById(definitionId, true, null);
       // suspendProcessInstances=true → suspend cả running instances
       log.info("Suspended process definition: {}", definitionId);
   }

   /**
    * Lấy BPMN XML từ deployed definition.
    * Useful cho: hiển thị diagram, audit, export.
    */
   public String getBpmnXml(String definitionId) {
       ProcessDefinition def = repositoryService.getProcessDefinition(definitionId);
       try (InputStream is = repositoryService.getResourceAsStream(
               def.getDeploymentId(), def.getResourceName())) {
           return new String(is.readAllBytes(), StandardCharsets.UTF_8);
       } catch (IOException e) {
           throw new RuntimeException("Failed to read BPMN resource", e);
       }
   }
}

@Service
@RequiredArgsConstructor
@Slf4j
public class ProcessInstanceService {

   private final RuntimeService runtimeService;

   /**
    * Start process instance.
    * businessKey = unique identifier từ business domain (order ID, loan ID).
    * Variables = initial data cho process.
    */
   public ProcessInstanceDTO startProcess(StartProcessRequest request) {
       Map<String, Object> variables = new HashMap<>();
       variables.put("applicantName", request.getApplicantName());
       variables.put("loanAmount", request.getLoanAmount());
       variables.put("applicationDate", LocalDate.now().toString());
       variables.put("workspaceId", request.getWorkspaceId());

       ProcessInstance instance = runtimeService.startProcessInstanceByKey(
           request.getProcessKey(),       // BPMN process ID (VD: "loan-approval")
           request.getBusinessKey(),      // Business identifier (VD: "LOAN-2024-001")
           variables
       );

       log.info("Process started | key={} | instanceId={} | businessKey={}",
           request.getProcessKey(), instance.getId(), request.getBusinessKey());

       return toDTO(instance);
   }

   /**
    * Gửi signal/message đến running instance.
    * Use case: external system callback, webhook response.
    */
   public void sendMessage(String messageName, String businessKey, Map<String, Object> payload) {
       // Find execution đang wait message
       Execution execution = runtimeService.createExecutionQuery()
           .messageEventSubscriptionName(messageName)
           .processInstanceBusinessKey(businessKey)
           .singleResult();

       if (execution == null) {
           throw new ProcessNotFoundException(
               "No process waiting for message: " + messageName + " with key: " + businessKey);
       }

       runtimeService.messageEventReceived(messageName, execution.getId(), payload);
       log.info("Message delivered | message={} | businessKey={}", messageName, businessKey);
   }

   /**
    * Get variables từ running instance.
    * Variables = shared state giữa tasks trong cùng instance.
    */
   public Map<String, Object> getVariables(String instanceId) {
       return runtimeService.getVariables(instanceId);
   }

   /**
    * Set/update variable dynamically.
    * Use case: external event update data giữa chừng process.
    */
   public void setVariable(String instanceId, String varName, Object value) {
       runtimeService.setVariable(instanceId, varName, value);
   }

   /**
    * Cancel running instance.
    * Use case: customer cancel application, admin abort stuck process.
    */
   public void cancel(String instanceId, String reason) {
       runtimeService.deleteProcessInstance(instanceId, reason);
       log.info("Process cancelled | instanceId={} | reason={}", instanceId, reason);
   }
}

@Service
@RequiredArgsConstructor
@Slf4j
public class UserTaskService {

   private final TaskService taskService;

   /**
    * Lấy tasks assigned cho user cụ thể.
    * "Inbox" của user — tasks đang chờ user hoàn thành.
    */
   public Page<TaskDTO> getMyTasks(String userId, Pageable pageable) {
       long total = taskService.createTaskQuery()
           .taskAssignee(userId)
           .count();

       List<Task> tasks = taskService.createTaskQuery()
           .taskAssignee(userId)
           .orderByTaskCreateTime().desc()
           .listPage((int) pageable.getOffset(), pageable.getPageSize());

       List<TaskDTO> dtos = tasks.stream().map(this::toDTO).toList();
       return new PageImpl<>(dtos, pageable, total);
   }

   /**
    * Lấy tasks available cho group (chưa ai claim).
    * "Shared queue" — ai rảnh thì nhận.
    */
   public List<TaskDTO> getGroupTasks(String groupId) {
       return taskService.createTaskQuery()
           .taskCandidateGroup(groupId)
           .taskUnassigned()  // Chưa ai claim
           .orderByTaskCreateTime().desc()
           .list()
           .stream()
           .map(this::toDTO)
           .toList();
   }

   /**
    * Claim task từ group queue.
    * Sau khi claim, task không còn visible cho người khác trong group.
    */
   public void claim(String taskId, String userId) {
       taskService.claim(taskId, userId);
       log.info("Task claimed | taskId={} | userId={}", taskId, userId);
   }

   /**
    * Unclaim — trả task về queue (user bận, không thể handle).
    */
   public void unclaim(String taskId) {
       taskService.unclaim(taskId);
   }

   /**
    * Complete task với output variables.
    * Variables này available cho downstream tasks/gateways.
    *
    * Ví dụ: Approver complete với decision="approve", comments="Looks good"
    * → Gateway đọc ${decision == 'approve'} → route accordingly
    */
   public void complete(String taskId, Map<String, Object> variables, String userId) {
       // Verify task assigned to this user
       Task task = taskService.createTaskQuery()
           .taskId(taskId)
           .taskAssignee(userId)
           .singleResult();

       if (task == null) {
           throw new TaskNotFoundException("Task not found or not assigned to you: " + taskId);
       }

       taskService.complete(taskId, variables);
       log.info("Task completed | taskId={} | taskName={} | userId={} | vars={}",
           taskId, task.getName(), userId, variables.keySet());
   }

   /**
    * Delegate task cho người khác.
    * Use case: manager delegate cho subordinate.
    */
   public void delegate(String taskId, String fromUserId, String toUserId) {
       taskService.delegateTask(taskId, toUserId);
       log.info("Task delegated | taskId={} | from={} | to={}", taskId, fromUserId, toUserId);
   }

   /**
    * Add comment to task (audit trail).
    */
   public void addComment(String taskId, String userId, String message) {
       Task task = taskService.createTaskQuery().taskId(taskId).singleResult();
       taskService.addComment(taskId, task.getProcessInstanceId(), message);
   }

   private TaskDTO toDTO(Task task) {
       Map<String, Object> variables = taskService.getVariables(task.getId());
       return TaskDTO.builder()
           .id(task.getId())
           .name(task.getName())
           .assignee(task.getAssignee())
           .createTime(task.getCreateTime().toInstant().atZone(ZoneId.systemDefault()).toLocalDateTime())
           .dueDate(task.getDueDate() != null ? task.getDueDate().toInstant().atZone(ZoneId.systemDefault()).toLocalDate() : null)
           .processInstanceId(task.getProcessInstanceId())
           .processDefinitionId(task.getProcessDefinitionId())
           .formKey(task.getFormKey())
           .variables(variables)
           .build();
   }
}

@Service
@RequiredArgsConstructor
public class ProcessHistoryService {

   private final HistoryService historyService;

   /**
    * Lấy toàn bộ history của 1 process instance.
    * Ai làm gì, khi nào, mất bao lâu — full timeline.
    */
   public ProcessHistoryDTO getInstanceHistory(String instanceId) {
       HistoricProcessInstance instance = historyService.createHistoricProcessInstanceQuery()
           .processInstanceId(instanceId)
           .singleResult();

       List<HistoricActivityInstance> activities = historyService.createHistoricActivityInstanceQuery()
           .processInstanceId(instanceId)
           .orderByHistoricActivityInstanceStartTime().asc()
           .list();

       List<HistoricTaskInstance> tasks = historyService.createHistoricTaskInstanceQuery()
           .processInstanceId(instanceId)
           .orderByHistoricTaskInstanceStartTime().asc()
           .list();

       return ProcessHistoryDTO.builder()
           .instanceId(instanceId)
           .startTime(instance.getStartTime())
           .endTime(instance.getEndTime())
           .durationMs(instance.getDurationInMillis())
           .status(instance.getEndTime() != null ? "COMPLETED" : "RUNNING")
           .activities(activities.stream().map(this::toActivityDTO).toList())
           .tasks(tasks.stream().map(this::toTaskDTO).toList())
           .build();
   }

   /**
    * Phân tích performance: average duration per task.
    * Phát hiện bottleneck: task nào mất thời gian nhiều nhất?
    */
   public List<TaskPerformanceDTO> getTaskPerformance(String processKey, LocalDate from, LocalDate to) {
       return historyService.createHistoricTaskInstanceQuery()
           .processDefinitionKey(processKey)
           .taskCompletedAfter(toDate(from))
           .taskCompletedBefore(toDate(to))
           .list()
           .stream()
           .collect(Collectors.groupingBy(HistoricTaskInstance::getName))
           .entrySet().stream()
           .map(entry -> {
               List<HistoricTaskInstance> tasks = entry.getValue();
               double avgDuration = tasks.stream()
                   .mapToLong(t -> t.getDurationInMillis() != null ? t.getDurationInMillis() : 0)
                   .average().orElse(0);
               return new TaskPerformanceDTO(
                   entry.getKey(),
                   tasks.size(),
                   (long) avgDuration,
                   tasks.stream().mapToLong(HistoricTaskInstance::getDurationInMillis).max().orElse(0)
               );
           })
           .sorted(Comparator.comparingLong(TaskPerformanceDTO::avgDurationMs).reversed())
           .toList();
   }
}

/**
* Delegate tính toán credit score.
*
* Input variables: customerId, loanAmount
* Output variables: creditScore, riskLevel, autoApproved
*
* BPMN reference: activiti:delegateExpression="${creditScoreDelegate}"
*/
@Component("creditScoreDelegate")
@RequiredArgsConstructor
@Slf4j
public class CreditScoreDelegate implements JavaDelegate {

   private final CreditScoringClient scoringClient;  // Gọi external service
   private final MetricsService metrics;

   @Override
   public void execute(DelegateExecution execution) {
       // 1. Read input variables
       String customerId = (String) execution.getVariable("customerId");
       BigDecimal loanAmount = (BigDecimal) execution.getVariable("loanAmount");
       String processId = execution.getProcessInstanceId();

       log.info("[processId={}] Calculating credit score | customerId={} | amount={}",
           processId, customerId, loanAmount);

       // 2. Execute business logic
       long start = System.nanoTime();
       try {
           CreditScoreResult result = scoringClient.calculate(customerId, loanAmount);

           // 3. Set output variables (available for downstream tasks/gateways)
           execution.setVariable("creditScore", result.getScore());
           execution.setVariable("riskLevel", result.getRiskLevel().name());
           execution.setVariable("autoApproved", result.getScore() >= 750);
           execution.setVariable("scoringDetails", result.getDetails());

           long durationMs = (System.nanoTime() - start) / 1_000_000;
           metrics.recordTaskDuration("credit_score_calculation", durationMs);

           log.info("[processId={}] Credit score calculated | score={} | risk={} | autoApproved={} | {}ms",
               processId, result.getScore(), result.getRiskLevel(),
               result.getScore() >= 750, durationMs);

       } catch (ScoringServiceUnavailableException e) {
           // Throw BpmnError → caught by boundary error event trên diagram
           log.error("[processId={}] Scoring service unavailable: {}", processId, e.getMessage());
           throw new BpmnError("SCORING_UNAVAILABLE",
               "Credit scoring service is temporarily unavailable");

       } catch (InvalidCustomerException e) {
           // Business error → route to rejection path
           execution.setVariable("rejectionReason", e.getMessage());
           throw new BpmnError("INVALID_CUSTOMER", e.getMessage());
       }
       // RuntimeException (NPE, etc.) → task fails, engine creates incident
       // → requires manual intervention or job retry
   }
}

<!-- 1. delegateExpression: Spring bean name (RECOMMENDED) -->
<!-- Bean phải implement JavaDelegate -->
<serviceTask activiti:delegateExpression="${creditScoreDelegate}"/>

<!-- 2. class: Full qualified class name (instantiated by engine, NOT Spring-managed) -->
<!-- ❌ KHÔNG inject Spring beans được (no @Autowired) -->
<serviceTask activiti:class="com.example.bpm.delegate.CreditScoreDelegate"/>

<!-- 3. expression: Call method trên Spring bean (không cần implement JavaDelegate) -->
<!-- Return value tự động set vào biến nếu có resultVariable -->
<serviceTask activiti:expression="${orderService.calculateTotal(execution)}"
            activiti:resultVariable="totalAmount"/>

<!-- Async service task: engine không block, delegate chạy bởi job executor -->
<serviceTask id="callExternalApi"
            activiti:delegateExpression="${externalApiDelegate}"
            activiti:async="true"
            activiti:exclusive="true"/>
<!--
 async="true": tạo job thay vì execute inline
 exclusive="true": không chạy song song với jobs cùng instance (tránh optimistic lock)
-->

@Configuration
public class AsyncExecutorConfig {

   @Bean
   public SpringProcessEngineConfiguration engineConfig(DataSource ds,
           PlatformTransactionManager txManager) {
       SpringProcessEngineConfiguration config = new SpringProcessEngineConfiguration();
       config.setDataSource(ds);
       config.setTransactionManager(txManager);

       // Async executor settings
       config.setAsyncExecutorActivate(true);
       config.setAsyncExecutorCorePoolSize(5);        // Minimum threads
       config.setAsyncExecutorMaxPoolSize(20);       // Maximum threads
       config.setAsyncExecutorDefaultAsyncJobAcquireWaitTime(5000);  // Poll interval (ms)
       config.setAsyncExecutorDefaultTimerJobAcquireWaitTime(5000);
       config.setAsyncFailedJobWaitTime(10);         // Seconds between retries
       config.setAsyncExecutorMaxAsyncJobsDuePerAcquisition(5);     // Jobs per batch

       // Retry configuration
       config.setDefaultFailedJobWaitTime(300);      // 5 minutes between retries
       config.setAsyncExecutorResetExpiredJobsInterval(60000);      // 1 minute

       return config;
   }
}

@Service
@RequiredArgsConstructor
@Slf4j
public class FailedJobService {

   private final ManagementService managementService;

   /**
    * Lấy jobs đang stuck (retries exhausted).
    * Monitor dashboard nên alert khi có deadletter jobs.
    */
   public List<DeadLetterJobDTO> getDeadLetterJobs() {
       return managementService.createDeadLetterJobQuery()
           .orderByJobCreateTime().desc()
           .list()
           .stream()
           .map(job -> DeadLetterJobDTO.builder()
               .jobId(job.getId())
               .processInstanceId(job.getProcessInstanceId())
               .exceptionMessage(job.getExceptionMessage())
               .createTime(job.getCreateTime())
               .retries(job.getRetries())
               .build())
           .toList();
   }

   /**
    * Retry dead letter job (sau khi fix root cause).
    * Move job từ deadletter → executable queue.
    */
   public void retryDeadLetterJob(String jobId) {
       managementService.moveDeadLetterJobToExecutableJob(jobId, 3); // 3 retries
       log.info("Dead letter job moved to executable | jobId={}", jobId);
   }
}

@Service
@RequiredArgsConstructor
public class TenantAwareProcessService {

   private final RepositoryService repositoryService;
   private final RuntimeService runtimeService;
   private final TaskService taskService;

   // Deploy với tenant isolation
   public String deploy(String bpmnXml, String name, String workspaceId) {
       Deployment deployment = repositoryService.createDeployment()
           .name(name)
           .tenantId(workspaceId)  // ← Tenant isolation
           .addString(name + ".bpmn20.xml", bpmnXml)
           .deploy();
       return deployment.getId();
   }

   // Start instance — tự động inherit tenant từ definition
   public String startProcess(String processKey, String workspaceId, Map<String, Object> vars) {
       ProcessInstance instance = runtimeService.startProcessInstanceByKeyAndTenantId(
           processKey, vars, workspaceId);  // ← Tenant-scoped
       return instance.getId();
   }

   // Query tasks — chỉ trong workspace
   public List<Task> getTasks(String userId, String workspaceId) {
       return taskService.createTaskQuery()
           .taskAssignee(userId)
           .taskTenantId(workspaceId)  // ← Tenant filter
           .list();
   }
}

@SpringBootTest
@ActiveProfiles("test")
class LoanApprovalProcessTest {

   @Autowired private RuntimeService runtimeService;
   @Autowired private TaskService taskService;
   @Autowired private HistoryService historyService;
   @Autowired private RepositoryService repositoryService;

   @MockBean private CreditScoringClient creditScoringClient;
   @MockBean private NotificationService notificationService;

   @BeforeEach
   void deployProcess() {
       repositoryService.createDeployment()
           .addClasspathResource("processes/loan-approval.bpmn20.xml")
           .deploy();
   }

   @Test
   void loanApproval_highCreditScore_autoApproved() {
       // Given: high credit score → auto-approve path
       when(creditScoringClient.calculate(any(), any()))
           .thenReturn(new CreditScoreResult(800, RiskLevel.LOW));

       // When: start process
       Map<String, Object> variables = Map.of(
           "customerId", "CUST-001",
           "loanAmount", new BigDecimal("500000000"),
           "applicantName", "Nguyen Van A"
       );
       ProcessInstance instance = runtimeService.startProcessInstanceByKey(
           "loan-approval", "LOAN-001", variables);

       // Then: process should complete automatically (no user task needed)
       HistoricProcessInstance completed = historyService.createHistoricProcessInstanceQuery()
           .processInstanceId(instance.getId())
           .finished()
           .singleResult();

       assertThat(completed).isNotNull();
       assertThat(completed.getEndTime()).isNotNull();

       // Verify notification sent
       verify(notificationService).sendApprovalNotification("CUST-001", "LOAN-001");
   }

   @Test
   void loanApproval_lowCreditScore_requiresManualReview() {
       // Given: low credit score → manual review path
       when(creditScoringClient.calculate(any(), any()))
           .thenReturn(new CreditScoreResult(550, RiskLevel.HIGH));

       // When: start process
       ProcessInstance instance = runtimeService.startProcessInstanceByKey(
           "loan-approval", "LOAN-002", Map.of(
               "customerId", "CUST-002",
               "loanAmount", new BigDecimal("2000000000")
           ));

       // Then: should create user task for manual review
       Task reviewTask = taskService.createTaskQuery()
           .processInstanceId(instance.getId())
           .taskDefinitionKey("manualReviewTask")
           .singleResult();

       assertThat(reviewTask).isNotNull();
       assertThat(reviewTask.getName()).isEqualTo("Manual Review");

       // Complete review with approval
       taskService.complete(reviewTask.getId(), Map.of(
           "decision", "approve",
           "reviewComments", "High amount but good collateral"
       ));

       // Verify process completed
       HistoricProcessInstance completed = historyService.createHistoricProcessInstanceQuery()
           .processInstanceId(instance.getId())
           .finished()
           .singleResult();
       assertThat(completed).isNotNull();
   }

   @Test
   void loanApproval_scoringServiceDown_errorPath() {
       // Given: scoring service throws error
       when(creditScoringClient.calculate(any(), any()))
           .thenThrow(new ScoringServiceUnavailableException("Service down"));

       // When: start process
       ProcessInstance instance = runtimeService.startProcessInstanceByKey(
           "loan-approval", "LOAN-003", Map.of(
               "customerId", "CUST-003",
               "loanAmount", new BigDecimal("100000000")
           ));

       // Then: should route to error handling path (manual scoring task)
       Task manualScoringTask = taskService.createTaskQuery()
           .processInstanceId(instance.getId())
           .taskDefinitionKey("manualScoringTask")
           .singleResult();

       assertThat(manualScoringTask).isNotNull();
       assertThat(manualScoringTask.getName()).isEqualTo("Manual Credit Assessment");
   }
}

@Component
@RequiredArgsConstructor
public class ProcessMetricsCollector {

   private final RuntimeService runtimeService;
   private final ManagementService managementService;
   private final HistoryService historyService;
   private final MeterRegistry meterRegistry;

   @Scheduled(fixedRate = 30000)  // Every 30s
   public void collectMetrics() {
       // Active instances
       long activeInstances = runtimeService.createProcessInstanceQuery().count();
       meterRegistry.gauge("bpmn.instances.active", activeInstances);

       // Suspended instances (paused, needs attention)
       long suspendedInstances = runtimeService.createProcessInstanceQuery().suspended().count();
       meterRegistry.gauge("bpmn.instances.suspended", suspendedInstances);

       // Pending user tasks (work backlog)
       long pendingTasks = managementService.createJobQuery().count();
       meterRegistry.gauge("bpmn.tasks.pending", pendingTasks);

       // Failed jobs (needs intervention)
       long failedJobs = managementService.createDeadLetterJobQuery().count();
       meterRegistry.gauge("bpmn.jobs.deadletter", failedJobs);

       // Timer jobs waiting (scheduled future work)
       long timerJobs = managementService.createTimerJobQuery().count();
       meterRegistry.gauge("bpmn.jobs.timer", timerJobs);
   }
}
